General Specifications
- Frequency Range
- 32 Hz – 300 Hz
- Power Rating
- IEC System Long-Term Ratings (low-Z direct) = 200 Watts Continuous Program Power ; 100 Watts Continuous Pink Noise (400W peak), 100 hr
- Sensitivity
- 95 dB (near corner), 89 dB (center of ceiling)
- Transformer Taps
- 80 W 40 W, 20 W, (& 10 W @ 70V), plus transformer bypass
- Impedance
- 8 ohms (in bypass mode)
- Drivers
- 200 mm (8 in) subwoofer
- Termination
- Screw-down removable locking clip-in connector
- Satellite Outputs
- Connectors for 2 or 4 Control 42C satellite speakers
- Included Accessories
- C-rings, tile rails, paint shield, cutout template, grille
- Maximum SPL (1m)
- 109 dB (low-impedance, 115 dB peak, center of ceiling) ; 115 dB (low-impedance, 121 dB peak near corner) ; 108 dB (70V/100V, center of ceiling) ; 114 dB (70V/100V near corner)
- Input Connectors
- 6 removeable locking 2-pin connectors with screwdown terminals
- Safety Agency
- Suitable for use in air handling spaces per UL1480, UL2043, NFPA90 & NFPA 70. S7232/UL Listed, Signaling Speaker. Transformer UL registered per UL1876. In accordance with IEC60849/EN60849.
- Backcan
- formed steel (included blind-mount)
- Baffle/Rim
- ABS baffle with UL94-V0 and UL94-5VB flame class fire rating
- Optional Accessories
- MTC-19NC New Construction Bracket, MTC-19MR Mud Ring Construction Bracket
- Plenum Usage
- Yes, backcan included
- Coverage Angle
- Omnidirectional
Dimensions
- Dimensions (Diameter x Depth)
- 332mm Diameter x 338mm Diameter Depth (13.1 in x 13.3 in)
- Ceiling Cutout Size
- 307 mm Diameter (12.1 in) (cardboard cutout template included)
- Weight
- 8.1 kg (17.9 lbs)
